Universal Adjustable Voltage Converter - 15W USB Type - C Power Supply Module (Deceive)

DC-DC CC CV Type-C USB Power Supply - Versatile 5V to 30V Converter Module

💍 The DC-DC CC CV Type-C USB Power Supply is an innovative and adaptable power converter module designed for various applications. With a robust capacity of 15W and a maximum output current of 2A, it serves as an efficient power supply for routers and other devices requiring reliable and adjustable voltage levels.

🔧 This powerful converter allows for seamless adjustment of the output voltage between 0.5V and 30V, accommodating a wide array of devices. The input voltage range spans from 4V to 13V, making it versatile for different setups. Its adjustable current limit feature from 0-2A ensures that sensitive electronics receive optimal power without risk of damage.

🧩 One of the standout features is its functionality as a USB charging cable, enabling users to modify both the charging voltage and maximum charging current to meet the needs of various batteries. The module incorporates constant current capability and anti-backflow protection, enhancing efficiency and safeguarding connected batteries during charging operations.

🧩 Safety is a top priority with multiple protective mechanisms integrated into the design, including:

• Short circuit protection
• Over-current protection
• Over-temperature protection
• Over-power protection
• Over-voltage protection
• Charging anti-backflow protection

🔍 The user interface includes an ON indicator light that clearly indicates when output is active, and a CC (Constant Current) indicator light to signify when the module is in constant current mode. Control is made simple with a dual-button system:

• Left Button: Short press to toggle ON/OFF or to decrease value in calibration mode; long press to set the default output state at power-on.
• Right Button: Short press to switch between displaying output voltage, current, and power; long press to access calibration mode.

🌟 The potentiometer knobs offer precise control over output voltage and current, allowing users to finely tune the settings based on their unique applications. The voltage adjustment potentiometer increases output voltage with a simple clockwise rotation, while the current adjustment potentiometer effectively sets the current limit, engaging constant current mode when the limit is reached.

Specifications:

• Input Voltage: 4-13V
• Output Voltage: 0.5-30V
• Output Current: 0-2A (adaptive based on load)
• Output Power: Up to 15W (automatic shut-off if exceeded)
• Voltage Resolution: 0.1V
• Current Resolution: 0.01A
• Power Display Range: 0.00W-15.0W
• Temperature Protection: Engages at 100°C
• Working Current: Approximately 30mA

🔋 This DC-DC converter module is ideal for desktop power supply applications, facilitating easy transitions between various voltage and current levels while also providing comprehensive protection features. Whether for charging or powering devices, it offers a reliable solution for electronics technicians, hobbyists, and anyone needing a flexible power supply system.
