🏆 Experience Unmatched Performance with Our Dual Way Bidirectional Brushed ESCs
⚙️ Designed for superior adaptability and efficiency, our series of Dual Way Bidirectional Brushed Electronic Speed Controllers (ESCs) cater to a wide range of RC models, including boats and tanks. From casual enthusiasts to seasoned hobbyists, these ESCs are engineered to deliver outstanding control and response across various brushed motors, providing an exceptional driving experience.
Model Specifications
5Ax2 ESC:
- Continuous Current: 5A
- Peak Current: 13A
- Power Input: 2S-3S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 500mA
- Weight: 15.5g
- Dimensions (L x W x H): 40 x 25 x 6.6 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 130, 180 brush motors
5Ax2 PRO ESC:
- Continuous Current: 5A
- Peak Current: 18A
- Power Input: 2S-6S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 800mA
- Weight: 20.5g
- Dimensions (L x W x H): 50 x 25 x 5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540/550 high current brush motors
10Ax2 ESC:
- Continuous Current: 10A
- Peak Current: 60A
- Power Input: 2S-6S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 800mA
- Weight: 21.5g
- Dimensions (L x W x H): 50 x 25 x 5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540 high current brush motors
20Ax2 ESC:
- Continuous Current: 20A
- Peak Current: 80A
- Power Input: 2S-6S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 1500mA
- Weight: 58g
- Dimensions (L x W x H): 50 x 25 x 5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540/550 high current brush motors
30Ax2 ESC:
- Continuous Current: 30A
- Peak Current: 120A
- Power Input: 2S-6S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 1500mA
- Weight: 58g
- Dimensions (L x W x H): 50 x 25 x 5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540/550 high current brush motors
🌿 40Ax2 ESC:
- Continuous Current: 40A
- Peak Current: 160A
- Power Input: 2S-4S LiPo (5S/6S may burn in seconds)
- Control Signal: PWM
- BEC Output: 5V @ 1500mA
- Weight: 65.7g
- Dimensions (L x W x H): 62 x 48 x 10 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540/550/775 high current brush motors
50Ax2 ESC:
- Continuous Current: 50A
- Peak Current: 320A
- Power Input: 3S-6S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 1500mA
- Weight: 70.3g
- Dimensions (L x W x H): 72 x 52 x 10 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 380/390/540/550/775 high current brush motors
60Ax2 ESC:
- Continuous Current: 60A
- Peak Current: 480A
- Power Input: 3S-7S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 2A
- Weight: 113g
- Dimensions (L x W x H): 65.5 x 53 x 27.5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 540/550/775/795 high current brush motors
120Ax2 ESC:
- Continuous Current: 120A
- Peak Current: 960A
- Power Input: 3S-7S LiPo
- Control Signal: PWM
- BEC Output: 5V @ 2A
- Weight: 130g
- Dimensions (L x W x H): 65.5 x 53 x 30.5 mm
- Mode Options: Mixed/Independent
- Applicable Motors: 540/550/775/795/D848 high current brush motors
💍 Package Options:
Select from various configurations to suit your needs, whether you require a single ESC or multiple units. Our offerings are tailored for flexibility in your RC projects, ensuring you have the power and control you need to navigate through your favorite terrains with ease.
