Product Overview:
🧩 Introducing the Advanced 3/4/5S BMS Balance Protection Board, expertly engineered for optimal performance and safety in lithium-ion battery applications. This versatile protection board is designed to cater to a range of configurations, accommodating battery packs with ratings of 10A, 15A, 20A, 25A, 30A, 40A, 60A, and even 100A for 12V and 24V systems. Whether you are working with 18650, 26650, or polymer-based lithium batteries, this board ensures enhanced functionality and reliability for your energy storage needs.
🔧 Key Features:
⚡ This BMS is compatible with ternary lithium batteries boasting a nominal voltage of 3.7V and a maximum full charge voltage of 4.2V. Its features include a charging voltage range of 12.6V to 13.6V, ensuring efficient power management. The board supports continuous discharge currents of up to 30A or 40A, providing flexibility based on your project's requirements. However, it is advisable to reduce the load current in environments with poor heat dissipation to avoid potential overheating.
Versions Available:
🛡️ The protection board comes in two versions: the Enhanced Version and the Balanced Version. The Enhanced Version is tailored for demanding applications, such as electric drills that require a starting current of 60A or less and a maximum power output of 130W. In contrast, the Balanced Version boasts an integrated balancing function, making it suitable for applications where consistent performance across battery cells is crucial.
Design Specifications:
🕊️ Measuring at 41mm x 55mm (Enhanced Version) or 41mm x 60mm (Balanced Version) with a lightweight design of just 8.8g and 9.8g respectively, this board is compact and easy to install in various projects. Its construction not only emphasizes durability but also enables seamless integration into your electrical systems.
🧩 Safety and Installation Notes:
🪶 For successful operation, adherence to wiring guidelines is vital. Ensure that connections are made precisely according to the wiring diagram (0V, 4.2V, 8.4V, 12.6V). During installation, avoid contact with any components on the board and do not create any short circuits. Be mindful that the "430" resistor may heat up during the initial charging phase as it functions within normal operating parameters; however, excessive heat could indicate wiring issues that must be rectified immediately.
🏆 Optimal Performance Recommendations:
🧩 For effective usage, employ three power batteries rated between 10C to 20C, or six lower-rated batteries, ensuring that all units in a battery pack have comparable capacity and internal resistance. This approach avoids the risks associated with mixing battery types, which can lead to diminished performance and safety concerns.
🧩 This BMS Balance Protection Board stands as a reliable solution for managing your lithium-ion battery systems, promoting longevity and safety for a wide array of applications.
