🏆 R350M High-Performance 13.56MHz RFID Reader for Access Control
🔴 The R350M series RFID reader stands at the forefront of innovative access control solutions, engineered to deliver rapid and dependable RFID card and keyfob reading capabilities. Operating at a frequency of 13.56MHz, the reader is compliant with industry standards such as ISO/IEC14443A/B and ISO15693, making it a reliable choice for diverse applications.
⚡ Designed with an advanced RF board, the R350M supports a broad spectrum of card types, including but not limited to:
- MIFARE Classic Mini/EV1
- MIFARE DESFire EV1/Light/EV2/EV3
- MIFARE Plus S/X
- MIFARE Ultralight/Ultralight C/Ultralight EV1
- NTAG2xx
- CPU cards
- Chinese Identity cards
🏛️ Equipped with standard Wiegand 26 and Wiegand 34 communication ports, the R350M series is tailored for a myriad of applications, including:
- Access control systems
- Time attendance monitoring
- Point of Sale (POS) systems
- Anti-theft measures
- Patrol operations
💍 Technical Specifications & Protocols
🏆 With exceptional technical parameters, the R350M series is designed for optimal performance:
- Supported Protocols: ISO/IEC14443A, ISO/IEC14443B, ISO15693
- Frequency: 13.56MHz
- Working Voltage: DC 12V (±5%)
- Operating Current: < 200mA
- Temperature Range: -10℃ to +60℃ operating; -20℃ to +80℃ storage
- Humidity: 15% to 90%
- Output Format: Configurable WG26, WG34, WG66
- Wiring Definitions: Red (VCC), Black (GND), White (D1), Green (D0), Purple (Beer), Gray (CLED), Yellow (output WG26 connect to GND)
- Dimensions: 86 x 86 x 15.6 mm (±0.3 mm tolerance)
⚡ Wide Application Scenarios
🔴 The R350M series is engineered to excel in various fields:
- Access Control: Ensures secure entry to offices, commercial buildings, and gated communities.
- Time Attendance: Streamlines employee attendance processes for maximum efficiency.
- Point of Sale Systems: Integrates seamlessly with payment methods and loyalty programs.
- Visitor Management: Efficiently tracks and manages guest access to facilities.
- Access Gates: Controls pedestrian and vehicle entry at critical junctures.
- Unmanned Supermarkets: Facilitates smooth self-service operations.
- Building Automation: Integrates with advanced smart building technologies.
- Elevator Control: Restricts access to specific floors as per organizational protocols.
🔒 Key Features & Advantages
🧩 The R350M reader boasts an array of features that enhance its functionality:
- High-Performance Microprocessor: Ensures rapid data processing with response times under 120 ms.
- Multi-Card Compatibility: Offers flexibility by supporting various RFID card types.
- Anti-Static & Anti-Misconnection Protections: Guarantees long-term reliability in demanding environments.
- Configurable Output Parameters: Allows customization of settings, including Wiegand format and card reading modes, through a simple configuration card.
- Cost-Effectiveness: Provides premium functionality without breaking the bank.
- Strong Anti-Interference Ability: Functions reliably in environments with high electromagnetic interference.
💎 Configuration & Customization
🎯 The R350M-B model enables hassle-free configuration with a swipe card, making it simple to adapt output formats (WG26, WG34, WG66) and card reading modes to fit individualized requirements, ensuring a tailored solution for each user.
Why Choose the R350M Series?
🏆 With its superior microprocessor technology, robust design, and extensive compatibility, the R350M series represents the pinnacle of RFID access control solutions. Whether for time attendance tracking, point of sale integration, or smart building applications, the R350M series delivers unparalleled performance, adaptability, and exceptional value for any organization.
